The GAP family of outdoor uplights/downlights is characterized by its low height, enabling it to be recessed in floors, ceilings or low walls. Depending on the installation surface, it must be installed with recessed box for concrete or with ring for suspended ceilings.

All are orientable and tilting models for LED, with a protection rating of IP67 and IK10, available in insulation class I.

The LED models are available for 5 or 10 LEDs in warm white, neutral or RGBW, and with Spot or Medium Flood optics. Thanks to its technical features, variety of models, optics and accessories, it fits perfectly in both indoor and outdoor areas and is ideal for general and spot lighting of walls, arches, porches, monuments, roundabouts, squares, parks, etc.

Products

Gap
CodeWKlm outGearFinishinglmGear
GA235WF840NI46º30W4000K2877-INOX3600Non-adjustableFloor recessed|Ceiling recessed
GA235WF830NI46º30W3000K2877-INOX3600Non-adjustableFloor recessed|Ceiling recessed
GA235SP840NI11º30W4000K2944-INOX3600Non-adjustableFloor recessed|Ceiling recessed
GA235SP830NI11º30W3000K2944-INOX3600Non-adjustableFloor recessed|Ceiling recessed
GA235MF840NI23º30W4000K2851-INOX3600Non-adjustableFloor recessed|Ceiling recessed
GA235MF830NI23º30W3000K2851-INOX3600Non-adjustableFloor recessed|Ceiling recessed
GA230WF840NI46º20W4000K2124-INOX2800Non-adjustableFloor recessed|Ceiling recessed
GA230WF830NI46º20W3000K2124-INOX2800Non-adjustableFloor recessed|Ceiling recessed
GA230SP840NI11º20W4000K2171-INOX2800Non-adjustableFloor recessed|Ceiling recessed
GA230SP830NI11º20W3000K2171-INOX2800Non-adjustableFloor recessed|Ceiling recessed
GA230MF840NI23º20W4000K2113-INOX2800Non-adjustableFloor recessed|Ceiling recessed
GA230MF830NI23º20W3000K2113-INOX2800Non-adjustableFloor recessed|Ceiling recessed
GA215WF840NI46º10W4000K1092-INOX1400Non-adjustableFloor recessed|Ceiling recessed
GA215WF830NI46º10W3000K1092-INOX1400Non-adjustableFloor recessed|Ceiling recessed
GA215SP840NI11º10W4000K1130-INOX1400Non-adjustableFloor recessed|Ceiling recessed
GA215SP830NI11º10W3000K1130-INOX1400Non-adjustableFloor recessed|Ceiling recessed
GA215MF840NI23º10W4000K1081-INOX1400Non-adjustableFloor recessed|Ceiling recessed
GA215MF830NI23º10W3000K1081-INOX1400Non-adjustableFloor recessed|Ceiling recessed

No results found for the current filters.

Downloads

Photometric data (Eulum Dat)
Installation instructions
Photometric data (IES)
