Fil 50
Fil is a comprehensive family of modular structures for suspending, surface mounting or recessing. Thanks to its diffusers reflectors, accessories and different dimensions offers great versatility, making it an ideal option for the general lighting in offices, hotels, restaurants, schools etc.
Fil is a profile made of satin grey or matt white lacquered extruded aluminium. Models for MID-POWER LED. Opal and prismatic polycarbonate diffuser and parabolic optics (on models for T5). With an IP20 or IP42 protection rating. Insulation class I.
Controllable under the Casambi protocol.
Custom-made possibilities
Dimmable 1-10V
Dimmable PUSH
Dimmable DALI
Bluetooth control
Colour rendering index
2700 K
Tunable White
Wellbeing
Lenghts
600 / 876 / 1137 / 1419 / 1700 / 1982 / 2274 / 2555 / 2836 mm
Formats
Corner
Finishes
Sensor Integration
Products
Fil 50 Opal Suspended/Surface
| Code | W | K | lm out | Gear | Length | Finishing | |
|---|---|---|---|---|---|---|---|
| F52SF120HOOP830NG | 37W | 3000K | 3566 | - | 1137mm | Grey | |
| F52SF120HOOP830NW | 37W | 3000K | 3566 | - | 1137mm | White | |
| F52SF120HOOP840NG | 37W | 4000K | 3761 | - | 1137mm | Grey | |
| F52SF120HOOP840NW | 37W | 4000K | 3761 | - | 1137mm | White | |
| F52SF120MOOP830DG | 19W | 3000K | 1900 | DALI | 1137mm | Grey | |
| F52SF120MOOP830DW | 19W | 3000K | 1900 | DALI | 1137mm | White | |
| F52SF120MOOP830NG | 19W | 3000K | 1900 | - | 1137mm | Grey | |
| F52SF120MOOP830NW | 19W | 3000K | 1900 | - | 1137mm | White | |
| F52SF120MOOP840DG | 19W | 4000K | 2004 | DALI | 1137mm | Grey | |
| F52SF120MOOP840DW | 19W | 4000K | 2004 | DALI | 1137mm | White | |
| F52SF120MOOP840NG | 19W | 4000K | 2004 | - | 1137mm | Grey | |
| F52SF120MOOP840NW | 19W | 4000K | 2004 | - | 1137mm | White | |
| F52SF170HOOP830NG | 55W | 3000K | 5349 | - | 1700mm | Grey | |
| F52SF170HOOP830NW | 55W | 3000K | 5349 | - | 1700mm | White | |
| F52SF170HOOP840NG | 55W | 4000K | 5642 | - | 1700mm | Grey | |
| F52SF170HOOP840NW | 55W | 4000K | 5642 | - | 1700mm | White | |
| F52SF170MOOP830NG | 28W | 3000K | 2850 | - | 1700mm | Grey | |
| F52SF170MOOP830NW | 28W | 3000K | 2850 | - | 1700mm | White | |
| F52SF170MOOP840NG | 28W | 4000K | 3006 | - | 1700mm | Grey | |
| F52SF170MOOP840NW | 28W | 4000K | 3006 | - | 1700mm | White | |
| F52SF170MOOP840DW | 28W | 4000K | 3006 | DALI | 1700mm | White | |
| F52SF170MOOP840DG | 28W | 4000K | 3006 | DALI | 1700mm | Grey | |
| F52SF170MOOP830DW | 28W | 3000K | 2850 | DALI | 1700mm | White | |
| F52SF170MOOP830DG | 28W | 3000K | 2850 | DALI | 1700mm | Grey |
Fil 50 Prismatic Suspended/Surface
| Code | W | K | lm out | Gear | Length | Finishing | |
|---|---|---|---|---|---|---|---|
| F52SF120HOPR830NW | 37W | 3000K | 3740 | - | 1137mm | White | |
| F52SF120HOPR840NG | 37W | 4000K | 3942 | - | 1137mm | Grey | |
| F52SF120HOPR840NW | 37W | 4000K | 3942 | - | 1137mm | White | |
| F52SF120MOPR830DG | 19W | 3000K | 1945 | DALI | 1137mm | Grey | |
| F52SF120MOPR830DW | 19W | 3000K | 1945 | DALI | 1137mm | White | |
| F52SF120MOPR830NG | 19W | 3000K | 1945 | - | 1137mm | Grey | |
| F52SF120MOPR830NW | 19W | 3000K | 1945 | - | 1137mm | White | |
| F52SF120MOPR840DG | 19W | 4000K | 2050 | DALI | 1137mm | Grey | |
| F52SF120MOPR840DW | 19W | 4000K | 2050 | DALI | 1137mm | White | |
| F52SF120MOPR840NG | 19W | 4000K | 2050 | - | 1137mm | Grey | |
| F52SF120MOPR840NW | 19W | 4000K | 2050 | - | 1137mm | White | |
| F52SF170HOPR830NG | 55W | 3000K | 5610 | - | 1700mm | Grey | |
| F52SF170HOPR830NW | 55W | 3000K | 5610 | - | 1700mm | White | |
| F52SF170HOPR840NG | 55W | 4000K | 5913 | - | 1700mm | Grey | |
| F52SF170HOPR840NW | 55W | 4000K | 5913 | - | 1700mm | White | |
| F52SF170MOPR830NG | 28W | 3000K | 2918 | - | 1700mm | Grey | |
| F52SF170MOPR830NW | 28W | 3000K | 2918 | - | 1700mm | White | |
| F52SF170MOPR840NG | 28W | 4000K | 3075 | - | 1700mm | Grey | |
| F52SF170MOPR840NW | 28W | 4000K | 3075 | - | 1700mm | White | |
| F52SF170MOPR840DW | 28W | 4000K | 3075 | DALI | 1700mm | White | |
| F52SF170MOPR840DG | 28W | 4000K | 3075 | DALI | 1700mm | Grey | |
| F52SF170MOPR830DW | 28W | 3000K | 2918 | DALI | 1700mm | White | |
| F52SF170MOPR830DG | 28W | 3000K | 2918 | DALI | 1700mm | Grey | |
| F52SF120HOPR830NG | 37W | 3000K | 3740 | - | 1137mm | Grey |
Fil 50 Opal Recessed
| Code | W | K | lm out | Gear | Length | Finishing | |
|---|---|---|---|---|---|---|---|
| F52RC120HOOP830NG | 37W | 3000K | 3566 | - | 1137mm | Grey | |
| F52RC120HOOP830NW | 37W | 3000K | 3566 | - | 1137mm | White | |
| F52RC120HOOP840NG | 37W | 4000K | 3761 | - | 1137mm | Grey | |
| F52RC120HOOP840NW | 37W | 4000K | 3761 | - | 1137mm | White | |
| F52RC120MOOP830DW | 19W | 3000K | 1900 | DALI | 1137mm | White | |
| F52RC120MOOP830NG | 19W | 3000K | 1900 | - | 1137mm | Grey | |
| F52RC120MOOP830NW | 19W | 3000K | 1900 | - | 1137mm | White | |
| F52RC120MOOP840DG | 19W | 4000K | 2004 | DALI | 1137mm | Grey | |
| F52RC120MOOP840DW | 19W | 4000K | 2004 | DALI | 1137mm | White | |
| F52RC120MOOP840NG | 19W | 4000K | 2004 | - | 1137mm | Grey | |
| F52RC120MOOP840NW | 19W | 4000K | 2004 | - | 1137mm | White | |
| F52RC170HOOP830NG | 55W | 3000K | 5349 | - | 1700mm | Grey | |
| F52RC170HOOP830NW | 55W | 3000K | 5349 | - | 1700mm | White | |
| F52RC170HOOP840NG | 55W | 4000K | 5642 | - | 1700mm | Grey | |
| F52RC170HOOP840NW | 55W | 4000K | 5642 | - | 1700mm | White | |
| F52RC170MOOP830NG | 28W | 3000K | 2850 | - | 1700mm | Grey | |
| F52RC170MOOP830NW | 28W | 3000K | 2850 | - | 1700mm | White | |
| F52RC170MOOP840NG | 28W | 4000K | 3006 | - | 1700mm | Grey | |
| F52RC170MOOP840NW | 28W | 4000K | 3006 | - | 1700mm | White | |
| F52RC170MOOP840DW | 28W | 4000K | 3006 | DALI | 1700mm | White | |
| F52RC170MOOP830DG | 28W | 3000K | 2850 | DALI | 1700mm | Grey | |
| F52RC170MOOP840DG | 28W | 4000K | 3006 | DALI | 1700mm | Grey | |
| F52RC170MOOP830DW | 28W | 3000K | 2850 | DALI | 1700mm | White |
Fil 50 Prismatic Recessed
| Code | W | K | lm out | Gear | Length | Finishing | |
|---|---|---|---|---|---|---|---|
| F52RC120HOPR830NG | 37W | 3000K | 3740 | - | 1137mm | Grey | |
| F52RC120HOPR830NW | 37W | 3000K | 3740 | - | 1137mm | White | |
| F52RC120HOPR840NG | 37W | 4000K | 3942 | - | 1137mm | Grey | |
| F52RC120HOPR840NW | 37W | 4000K | 3942 | - | 1137mm | White | |
| F52RC120MOOP830DG | 19W | 3000K | 1900 | DALI | 1137mm | Grey | |
| F52RC120MOPR830DG | 19W | 3000K | 1945 | DALI | 1137mm | Grey | |
| F52RC120MOPR830DW | 19W | 3000K | 1945 | DALI | 1137mm | White | |
| F52RC120MOPR830NG | 19W | 3000K | 1945 | - | 1137mm | Grey | |
| F52RC120MOPR830NW | 19W | 3000K | 1945 | - | 1137mm | White | |
| F52RC120MOPR840DG | 19W | 4000K | 2050 | DALI | 1137mm | Grey | |
| F52RC120MOPR840DW | 19W | 4000K | 2050 | DALI | 1137mm | White | |
| F52RC120MOPR840NG | 19W | 4000K | 2050 | - | 1137mm | Grey | |
| F52RC120MOPR840NW | 19W | 4000K | 2050 | - | 1137mm | White | |
| F52RC170HOPR830NG | 55W | 3000K | 5610 | - | 1700mm | Grey | |
| F52RC170HOPR830NW | 55W | 3000K | 5610 | - | 1700mm | White | |
| F52RC170HOPR840NG | 55W | 4000K | 5913 | - | 1700mm | Grey | |
| F52RC170HOPR840NW | 55W | 4000K | 5913 | - | 1700mm | White | |
| F52RC170MOPR830NG | 28W | 3000K | 2918 | - | 1700mm | Grey | |
| F52RC170MOPR830NW | 28W | 3000K | 2918 | - | 1700mm | White | |
| F52RC170MOPR840NG | 28W | 4000K | 3075 | - | 1700mm | Grey | |
| F52RC170MOPR840NW | 28W | 4000K | 3075 | - | 1700mm | White | |
| F52RC170MOPR840DW | 28W | 4000K | 3075 | DALI | 1700mm | White | |
| F52RC170MOPR840DG | 28W | 4000K | 3075 | DALI | 1700mm | Grey | |
| F52RC170MOPR830DW | 28W | 3000K | 2918 | DALI | 1700mm | White | |
| F52RC170MOPR830DG | 28W | 3000K | 2918 | DALI | 1700mm | Grey |
